Stahl PTB 01 Atex 1044 Coupling Socket

Name: STAHL PTB 01 ATEX 1044 COUPLING SOCKET
SKU: 1056509
Availability: LimitedAvailability

stahl-PTB-01-ATEX-1044-coupling-socket-(new)

stahl-PTB-01-ATEX-1044-coupling-socket-(new)-1

stahl-PTB-01-ATEX-1044-coupling-socket-(new)-2

新着

在庫あり1 ユニット即納可能

Coupling Socket

The Stahl PTB01ATEX1044 coupling socket offers a rated current of 16 A with insulation voltage up to 750 V. It is designed for reliable connections in hazardous environments, featuring a wide operating temperature range and versatile voltage options.

メーカー

STAHL

SKU

1056509

カテゴリ

Cables & Connectors

コンディション

大量在庫

グローバル配送

専門的なサポート

品質保証

Stahl PTB01ATEX1044 “ Coupling Socket

The Stahl PTB01ATEX1044 coupling socket is designed for reliable electrical connections in hazardous environments. With a high-rated current capacity and versatile operating voltage, this device ensures safe and efficient operation in industrial applications.

Manufacturer: Stahl

Type: Coupling Socket

Model: PTB01ATEX1044

Part No.: 8575/12-506

COMAS part No.: 0.476.085.002.020 / 472.999.000.115

Ambient Temperature:

Rated Insulation Voltage	up to 750 V
Rated Operating Voltage	Plug-and socket device up to 690 V, Auxiliary contact 240/415 V
Rated Current (le max.)	Plug-and socket device 16 A, Auxiliary contact 6 A
Rated Connection	4 mm²
Frequency	50 to 60 Hz
Thermal class T6	-45 °C to 45 °C
Thermal class T5	-45 °C to 55 °C
