ABB AF12-30-10-11 Contactor
신제품
재고 있음1 단위즉시 배송 가능
효율적인 모터 제어를 위해 설계된 고품질 산업용 접촉기. 24-60V AC/DC 코일 전압, 35A 열전류, IP20 보호 기능을 갖추어 내구성과 신뢰성을 보장합니다.
24-60V60947-4-1ABBAF12301011AutomationComponentsContactorControlCurrentforHighIec/EnIndustrialIP20MmotorRatedscrewterminal
방대한 재고
글로벌 배송
전문 지원
품질 보장
ABB AF12301011 Contactor
The ABB AF12301011 is a high-performance industrial contactor designed for efficient control of electrical circuits. It is engineered to handle high currents with exceptional reliability, making it ideal for industrial automation and motor control applications.
Key Details:
Manufacturer: ABB
Type: Contactor
Model: AF12301011
ID No.: 1SBL157001R1110
EAN: 3471523110311
The ABB AF12301011 contactor is an ideal solution for industrial motor control applications, providing high durability, reliability, and compliance with international standards.
| Coil Voltage | 24 to 60 V AC/DC |
| Frequency | 50/60 Hz |
| Conventional Free-air Thermal Current (Ith) | 35 A |
| Rated Impulse Withstand Voltage (Uimp) | 6 kV |
| Insulation Voltage (Ui) | 690 V AC |
| Thermal Current (Ith) | 35 A |
| Rated Operational Current AC-1 (Ie) | 28 A |
| Rated Operational Power AC-3 (Pe) | (400 V) 5.5 kW |
| Rated Operational Power AC-8a (Pe) | (400 V) 7.5 kW |
| Auxiliary Contacts | 1 Normally Open |
| Number of Poles | 2 |
| Terminal Type | Screw Terminals |
| General Use Rating UL/CSA | (600 V AC) 28 A |
| Protection Class | IP20 |
| Ambient Air Temperature | -25 to 60 °C |
| Standards | IEC/EN 60947-4-1, GB14048.4 |
| Dimensions | 45 x 77 x 86 mm |
