INDUCTIVE SENSOR

Balluff BES M12MI-PSC20B-S04G is a flush-mountable inductive standard sensor with 2 mm sensing range, IP68 protection, and durable nickel-plated brass housing for industrial environments.

제조업체

BALLUFF

SKU

1078142

카테고리

Sensors

상태

중고

Balluff BES brass Connector Flush Frequency High Inductive Industrial IP68 M12 M12MI-PSC20B-S04G mount nickel-plated Output PNP Sensor Threaded

방대한 재고

글로벌 배송

전문 지원

품질 보장

BALLUFF BES M12MI-PSC20B-S04G INDUCTIVE STANDARD SENSOR

The Balluff BES M12MI-PSC20B-S04G is a high-performance inductive standard sensor with base, engineered for precision detection in industrial environments. Featuring flush mounting and a robust IP68-rated housing, it ensures reliable performance in harsh conditions. Ideal for automation systems requiring fast switching and consistent operation.

Manufacturer: BALLUFF

Type: Inductive Standard Sensor with Base

Model: BES M12MI-PSC20B-S04G

Sensing Range	2 mm
Operating Voltage	10 / 30 V DC
Switching Frequency	3500 Hz
Operating Current	200 mA DC
Electrical Design	PNP
Output Function	Normally Open
Connector Type	M12 Connector, 4 “ Pin
Protection Class	II
Enclosure Rating	IP68
Housing	Threaded Type
Ambient Operating Temperature	“25 / 70°C
Diameter, Housing Length	12, 65 mm
Material	Nickel-Plated Brass
Mounting	Flush Mountable
