Bielomatik AM Single Piston Pump
신제품
재고 있음2 단위즉시 배송 가능
299,99$
Single Piston Pump
The BIELOMATIK AM Single Piston Pump provides efficient fluid transfer with 60 bar max pressure, 1.5-3.0 liter filling quantity, and a compact pneumatic drive. Features IP67 protection and 24 V DC operation for industrial applications.
방대한 재고
글로벌 배송
전문 지원
품질 보장
BIELOMATIK AM Single Piston Pump
The BIELOMATIK AM Single Piston Pump is designed for efficient and reliable fluid transfer in industrial applications. With a pneumatic drive, it offers a high-pressure rating of 60 bar, a filling quantity range of 1.5 to 3.0 liters, and a displacement of 25.0 cm³ per stroke. This pump is ideal for applications requiring precise fluid control and a durable, compact design.
Manufacturer: BIELOMATIK
Type: Single Piston Pump
Model: AM
Part No.: 30011588
Ref No.: 07022003
Technical Data:
- Max Operating Pressure: 60 bar
- Filling Quantity: 1.5 / 3.0 litres
- Pump Pressure: 60 bar
- Displacement: 25.0 cm³/stroke
- Type of Drive: Pneumatic
- Drive Supply Pressure: 4 / 6 bar
- Ambient Temperature: 0 to 80 °C
- Filling: Manual
- Protection Class (EN60529): IP67
- Supply Fitting: G ¼
- Nominal Voltage: 24 V DC
- Power Consumption: 17 mA
- Switching Current: 100 mA
- Connection: M8 x 1
