GF Signet P51530-P0 Paddlewheel Flow Sensor
신제품
요청 시 제공 가능
200,00$
방대한 재고
글로벌 배송
전문 지원
품질 보장
Manufacturer: +GF+
Type: Flow Sensor
Part No.: P51530-P0
Code: 198 801 620
Supply voltage: 5 … 24 V DC
Current: <20 mA @ 6 to 24 VDC
Pressure/Temperature Rating: 1.7 bar max @ 90 °C ,
12.5 bar max @ 20 °C
Operating temp.: -18 °C to 66 °C
Flow Rate Range: 0.3 … 6 m/s
Cable length: 7.6 m standard, max. 60 m
Cable type: 2-conductor twisted pair w/ shield (22 AWG)
Pipe Size: 0.5 … 4 inch
Body: Polypropylene
Rotor/Pin: Black PVDF/Titanium
Weight: 0.44 kg
