Hager ES430 Contactor
신제품
재고 있음10 단위즉시 배송 가능
Hager Override 접촉기 ES 430, 400 V AC에서 13 kW 접촉 전력, 20 A 전류 등급 및 20 A 정격 열 전류를 갖추고 있습니다. 산업 및 상업 회로에서 효율적인 작동을 위해 설계되었습니다.
1320354006185aAbsorbedACAC1closeContactContactorCurrentHagerIndustrialInrushkWmmNormallyOperatingoperationalOverridePowerRatedTemperatureThermalVvoltagex
방대한 재고
글로벌 배송
전문 지원
품질 보장
Hager Override Contactor ES 430
Hager Override Contactor ES 430 is a high-quality contactor designed for efficient switching and protection in electrical circuits. It offers reliable performance in demanding environments, with features optimized for industrial and commercial applications.
- Manufacturer: Hager
- Type: Override Contactor
- Model: ES 430
- Part No.: 239430
Technical Data:
- Rated Operational Voltage (Ue): 400 V AC
- Frequency: 50 Hz
- Rated Insulation Voltage (Ui): 400 V AC
- Rated Impulse Withstand Voltage (Uimp): 4 kV
- Command Voltage: 230 V AC
- Contact Power: 13 kW at 400 V AC
- Acceptable Current Rating with AC1: 20 A
- Thermal Rated Current (Ith): 20 A
- Contact: 4 Normally Close
- Inrush Power Absorbed: 20 VA
- Operating Consumption: 5 VA
- Total Power Loss under In: 4.8 W
- Power Loss per Contact: 1.2 W
- Operating Temperature: -10 to 50 °C
- Dimensions: 61 x 85 x 35 mm
