IFM LMC100 Sensor FOR Point Level Detection

Manufacturer: IFM
Type: Sensor for point level detection
Model: LMC 100
MRN: LMFCE-B12E-QSKG-0/US

Number of digital outputs: 2
Output signal: switching signal; IO-Link
Electrical design: PNP/NPN
Factory setting: water: hydrous media
Process connection: G 1/2 external thread
Media: water; hydrous media; oils; oil-based media; coolants; powder
Electrical connection: 4-pin
Max. voltage drop switching output DC: 2.5 V
Medium temperature: -25…100 °C
Probe length: 28 mm
Tank pressure: -1…40 Bar
MAWP (for applications according to CRN): 40 bar
Operating voltage: 18…30 VDC
Current consumption: 35 Ma
Ambient temperature: -25…85 °C
Materials: stainless steel
