Keyence FS-V11P Fiber Amplifier Sensor
신제품
재고 있음1 단위즉시 배송 가능
Fiber Amplifier The Keyence FS-V11P is a high-speed fiber amplifier sensor main unit designed for industrial sensing applications. It features a 12 to 24 VDC power supply, red LED light source, ultra-fast response times, PNP open-collector output, selectable LIGHT-ON/DARK-ON modes, and a durable polycarbonate housing for reliable automation performance.
방대한 재고
글로벌 배송
전문 지원
품질 보장
| Part No. | 1126118 |
| Main unit/Expansion unit | Main unit |
| Power voltage | 12 to 24 VDC |
| Current consumption | 50 mA or less |
| Light source | Red LED |
| Response time | 250 µs (FINE) /500 µs (TURBO) /1 ms (SUPER TURBO) |
| Operation mode | LIGHT-ON/DARK-ON (switch-selectable) |
| Control output | PNP open-collector 100 mA max. (40 V),Residual voltage: 1 V max. |
| Indicator lamp | Display indicator: Red LED |
| Timer function | ON-delay: 40 ms /OFF-delay: 10 ms /Timer OFF (switch-selectable) |
| Case material | Polycarbonate |
| Ambient temperature | -10 to +55 °C |
| Condition | New |
| Stock key | JO-004 |
| SKU | 1098127 |
| Weight | 0,11 |
