Pressure Switches

Krohne PSM2010 Electronic Pressure Switch

Name: KROHNE PSM2010 ELECTRONIC PRESSURE SWITCH
SKU: 1083935
Availability: LimitedAvailability

Krohne-psm2010-electronic-pressure-switch(new)

Krohne-psm2010-electronic-pressure-switch(new)-1

Krohne-psm2010-electronic-pressure-switch(new)-2

Krohne-psm2010-electronic-pressure-switch(new)-3

Krohne-psm2010-electronic-pressure-switch(new)-4

Krohne-psm2010-electronic-pressure-switch(new)-5

Krohne-psm2010-electronic-pressure-switch(new)-6

신제품

재고 있음3 단위즉시 배송 가능

Electronic Pressure Switch

The KROHNE PSM2010 from the OPTIBAR series provides accurate 0 to 6.0 bar measurement with stainless steel 316L housing, 4 digit LED display, and multiple output options including PNP, NPN, IO-Link, mA, and V.

제조업체

KROHNE

SKU

1083935

카테고리

Pressure Switches

상태

신제품

0 4 6 bar Connector Control Electronic Industrial IO-Link Krohne M12 NPN Optibar pin PNP Pressure PSM2010 Sensor stainless Steel Switch to

방대한 재고

글로벌 배송

전문 지원

품질 보장

KROHNE PSM2010 Electronic Pressure Switch

The KROHNE PSM2010 Electronic Pressure Switch from the OPTIBAR series offers accurate and reliable pressure monitoring for industrial applications. Built with a stainless steel 316L housing and an easy-to-read LED display, it ensures durability, precision, and versatility in process control systems.

Manufacturer: KROHNE

Type: Electronic Pressure Switch

Model: PSM2010

MRN: VGKY4RG0S30V00SM1M00

Serial No.: P210001011156176

Series: OPTIBAR

Measuring Range	0 to 6.0 bar
Maximum Working Pressure	40 bar
Output Signal	PNP, NPN, IO-Link, mA, V
Power Supply (SUP)	18 to 30 VDC
Electrical Connection	M12 4 pin connector
Process Connection	G 1/2
Display	4 digit LED, switchable units (bar, mbar, PSI, MPa)
Housing Material	Stainless Steel 316L
Seal Material	FKM
