MIN-TEC 46480-001 Connector
신제품
재고 있음2 단위즉시 배송 가능
커넥터 MIN-TEC W12M5A2-008-A는 내구성과 신뢰성을 위해 제작된 5극 산업용 커넥터입니다. IP67 보호 기능, 금도금 접점이 있으며 -40°C에서 +85°C까지의 극한 온도에서 작동합니다.
방대한 재고
글로벌 배송
전문 지원
품질 보장
MIN-TEC W12M5A2-008-A Connector
The MIN-TEC W12M5A2-008-A is a robust and reliable 5-pole industrial connector engineered for high-performance electrical applications. With a durable build and IP67 protection, it offers secure, long-lasting connections even in harsh environments.
Manufacturer: MIN-TEC
Type: Connector
Model: W12M5A2-008-A
MRN: 46480-001
Technical Data:
- Code/Initials: W12
- Reference Norm: IEC 61076-2-101
- Protection Degree: IP67
- Pollution Degree: 3
- Operating Temperature: -40°C to +85°C
- No Unscrewing Ring-Nut: Nickel-plated
- Contacts Material: Gold-plated Brass
- External Insulation: Polyamide 66 GF25
- Contacts Holder: PA Plastic
- Gasket: Silicone
- Number of Poles: 5
- Max Rating Voltage: 60V
- Max Rating Current: 4A
