Moeller T0-1-15402/E Changeover Switch
신제품
재고 있음1 단위즉시 배송 가능
Moeller / Eaton 전환 스위치 T0115402/E, 정격 전압 960 V AC, 전류 12 A, 차단 용량 110 A. IP65 보호, 토글 액추에이터 및 매립형 설치로 신뢰할 수 있는 산업용 애플리케이션에 적합합니다.
1“1012960aActuatorBreakingCapacityChangeoverControlCurrentEatonFlushIndustrialIP65MoellerMountingProtectionRatedSwitchToggleVvoltage
방대한 재고
글로벌 배송
전문 지원
품질 보장
Moeller / Eaton Changeover Switch T0115402/E
Moeller / Eaton Changeover Switch T0115402/E is a versatile and reliable control switch designed for industrial applications. It ensures secure and efficient switching between operational states with features such as high rated voltage, operational current, and durable protection standards.
- Manufacturer: Moeller / Eaton
- Type: Changeover Switch / Control Switch
- Model: T0115402/E
- Series: T0
Technical Data:
- Rated Voltage Ue: 960 V AC
- Rated Current Ie: 12 A
- Rated Operational Current at AC-15 at 415 V: 4 A
- Rated Breaking Capacity at 400/415 V: 110 A
- Rated Operational Power at AC-23A at 380 to 440 V: 6.5 kW
- Rated Operational Power at AC-3 at 380 to 440 V: 4/2.2 kW
- Rated Impulse Voltage (Uimp): 6 kV
- Switching Angle: 45 degrees
- Number of Contacts: 2
- Number of Poles: Two-pole
- Pollution Degree: 3
- Actuator Type: Toggle
- Fitted With: Black thumb grip and front plate with 0 (off) position inscription: 0-1
- Mounting: Flush mounting
- Protection Class: IP65
- Standard: IEC 947, EN 60947, VDE 0660
- Ambient Operating Temperature: -25 to 50 °C
- Dimensions: 76 x 48 x 48 mm
