Omron E3F2-DS30B4 Photoelectric Sensor

재고 있음4 단위즉시 배송 가능

66,66$

PHOTOELECTRIC SENSOR Omron E3F2DS30B4 확산 반사형 광전 센서, 감지 거리 300mm, PNP 출력, 10~30 V DC 전원, IP67 보호 등급, 적외선 LED 광원.

제조업체
OMRON
SKU
1009586
카테고리
Sensors
상태
신제품
공유
방대한 재고
글로벌 배송
전문 지원
품질 보장

Omron E3F2DS30B4 Photoelectric Sensor (Diffuse Reflective)

The Omron E3F2DS30B4 is a compact and reliable photoelectric sensor with diffuse-reflective sensing technology. Designed for accurate object detection up to 300 mm, it offers flexible wiring options, PNP output, and IP67 protection for use in demanding industrial automation environments.

Manufacturer: Omron

Type: Photoelectric Sensor / Diffuse Reflective

Model: E3F2DS30B4

Sensing MethodDiffuse-Reflective
Sensing Distance300 mm
Connection MethodPre-wired (2 m)
Operating Voltage10 / 30 V DC
Current Consumption30 mA max
Operating Current100 mA max
Response Time2.5 ms max
Electrical DesignPNP
Control OutputTransistor (open collector), load current 100 mA max
Protection DegreeIP67
Light Source (Wavelength)Infrared LED (880 nm)
Operation ModeLight-ON or Dark-ON selectable by wiring
Sensitivity AdjustmentAdjustable
Ambient Temperature-25 / 55 °C
Housing Material (Case)Plastic
