PMI MSB35S Linear Guideway Block
신제품
재고 있음6 단위즉시 배송 가능
방대한 재고
글로벌 배송
전문 지원
품질 보장
Manufacturer: PMI
Type: LINEAR GUIDEWAY BLOCK
Series: MSB
Model: MSB 35S
MRN: MSB35SSSFCNY
Size: 35
Block Type: Square
Load Type: Heavy load
Block Mounting Type: Top or bottom
Block Height: 48 mm
Block Width: 70 mm
Block Length: 112 mm
Thread Size: M8
Rail Width: 34 mm
Rail Height: 27.5 mm
Preload: FC
Accuracy Grade: N
Basic dynamic load rating: 52 kN
Basic static load rating: 75.5 kN
Weight: 1.28 kg
