Puls UB10.242 DC-UPS Control Unit
DC-UPS 제어 장치 PULS DC-UPS 제어 장치 UB10.242는 24V 입력 및 15A 출력으로 효율적인 전원 백업을 위해 설계되었습니다. 특징으로는 온도 추적 기능이 있는 배터리 충전, 과부하 보호 및 50% 전원 예비가 포함됩니다. 17Ah에서 130Ah 배터리와 호환되며 3년 보증이 제공됩니다.
PULS DC-UPS Control Unit UB10.242
The PULS DC-UPS Control Unit UB10.242 is designed for reliable and efficient power backup in critical systems. It only requires a single 12V battery to provide a stable 24V output, making it highly versatile and energy-efficient. The unit is compatible with batteries between 17Ah and 130Ah and offers advanced features such as battery charging with temperature tracking, overload protection, and superior battery management for extended battery life. With comprehensive diagnostic and monitoring functions, this unit ensures reliable operation and provides a replace battery signal when needed.
Manufacturer: PULS
Type: DC-UPS Control Unit
Part No.: UB10.242
Technical Specifications
- Input Voltage Nom.: 24V DC
- Range Voltage: 22.5-30V DC
- Output Current Min. (Normal Mode): 15 A
- Output Current Min. (Buffer Mode): 10 A
- Output Voltage Nom.: 0.23V lower than input voltage
- Allowed Batteries: 17Ah to 130Ah
- Temperature Range: -25 to 50°C
- Dimensions (WxHxD): 49 x 124 x 117 mm
- Features:
- Requires only one 12V battery for a 24V output
- Battery charging with temperature tracking
- Stable output voltage in buffer mode
- Superior battery management for longest battery life
- Comprehensive diagnostic and monitoring functions
- Replace battery signal included
- Electronically overload and short circuit protected
- 50% power reserves
- 3-year warranty
