PULS DC-UPS Control Unit UB10.242
The PULS DC-UPS Control Unit UB10.242 is designed for reliable and efficient power backup in critical systems. It only requires a single 12V battery to provide a stable 24V output, making it highly versatile and energy-efficient. The unit is compatible with batteries between 17Ah and 130Ah and offers advanced features such as battery charging with temperature tracking, overload protection, and superior battery management for extended battery life. With comprehensive diagnostic and monitoring functions, this unit ensures reliable operation and provides a replace battery signal when needed.
Manufacturer: PULS
Type: DC-UPS Control Unit
Part No.: UB10.242
Technical Specifications
- Input Voltage Nom.: 24V DC
- Range Voltage: 22.5-30V DC
- Output Current Min. (Normal Mode): 15 A
- Output Current Min. (Buffer Mode): 10 A
- Output Voltage Nom.: 0.23V lower than input voltage
- Allowed Batteries: 17Ah to 130Ah
- Temperature Range: -25 to 50°C
- Dimensions (WxHxD): 49 x 124 x 117 mm
- Features:
- Requires only one 12V battery for a 24V output
- Battery charging with temperature tracking
- Stable output voltage in buffer mode
- Superior battery management for longest battery life
- Comprehensive diagnostic and monitoring functions
- Replace battery signal included
- Electronically overload and short circuit protected
- 50% power reserves
- 3-year warranty
