Rinck Electronic MV-PT100 Measuring Amplifier

Name: RINCK ELECTRONIC MV-PT100 MEASURING AMPLIFIER
SKU: 1079351
Availability: LimitedAvailability

rinck-electronic-MV-PT100-measuring-amplifier-(Used)

rinck-electronic-MV-PT100-measuring-amplifier-(Used)-1

rinck-electronic-MV-PT100-measuring-amplifier-(Used)-2

중고

재고 있음1 단위즉시 배송 가능

MEASURING AMPLIFIER

Rinck Electronic MV-PT100 measuring amplifier for PT100 RTD sensors with 24 V AC/DC supply, voltage and current outputs, and compact industrial design.

제조업체

RINCK ELECTRONIC

SKU

1079351

카테고리

Safety Relays

상태

중고

24v AC Amplifier AND Converter Current dc Device Electronic Industrial Measuring Module mv-pt100 Output Pt100 rinck RTD Sensor Signal voltage

방대한 재고

글로벌 배송

전문 지원

품질 보장

RINCK ELECTRONIC MV-PT 100 MEASURING AMPLIFIER

The Rinck Electronic MVPT100 is a high-precision measuring amplifier designed for PT100 sensors, delivering reliable conversion to standardized output signals. Built for industrial environments, it ensures accurate monitoring and control across a wide range of applications.

Manufacturer: RINCK ELECTRONIC

Type: Measuring Amplifier

Model: MV-PT100

Function	Converter for PT100 Sensor
Supply Voltage	24 V AC/DC
Power Current Max.	70 mA
Input Sensor	PT100 RTD
Output Voltage Pin 1-2	0 / 10 V DC (2 / 10 V DC)
Output Current Max.	20 mA
Output Signal Pin 2-3	0 / 20 mA (4 / 20 mA)
Output Load Resistor Max.	800 Ohm
Ambient Temperature	-10 / 50 °C
Dimensions	72 x 24 x 94 mm
