Siemens 6AV2 123-2MB03-0AX0 Basic Panel
신제품
요청 시 제공 가능
900,00$
Basic HMI Panel
A 12-inch SIMATIC HMI Basic Panel featuring a high-resolution TFT widescreen display, multi-language support, and reliable 24 V DC operation for industrial monitoring and control applications.
방대한 재고
글로벌 배송
전문 지원
품질 보장
Siemens SIMATIC HMI KTP1200 Basic Panel
A high-performance human-machine interface designed for industrial automation systems, providing clear visualization, intuitive operation, and reliable performance in control and monitoring applications. This panel is part of the SIMATIC HMI Basic family and is optimized for PROFINET-based environments. Manufacturer: Siemens
Type: Basic Panel
Family: SIMATIC HMI
MRN: 6AV2123-2MB03-0AX0
Product Type Designation: KTP1200 Basic color PN
| Display Type | TFT widescreen display, LED backlighting |
| Screen Diagonal | 12 in |
| Display Width | 261.1 mm |
| Display Height | 163.2 mm |
| Number of Colors | 65,536 |
| Resolution | 1280 x 800 pixels |
| Backlighting MTBF (at 25 °C) | 20,000 h |
| Supply Voltage Type | DC |
| Rated Voltage | 24 V DC |
| Permissible Voltage Range | 19.2 V DC to 28.8 V DC |
| Current Consumption (Rated) | 510 mA |
| Active Power Input (Typical) | 12.2 W |
| Ambient Temperature During Operation (Vertical Installation) | 0 °C to +50 °C |
| Number of Online / Runtime Languages | 10 |
| Project Languages Per Project | 32 |
| Number of Alarm Classes | 32 |
