Tekel TK256 Incremental Encoder
신제품
재고 있음6 단위즉시 배송 가능
215,00$
INCREMENTAL ENCODER TEKEL TK 256는 2000 PPR, 8 mm 실축 및 RS422 line driver 출력을 특징으로 하는 고해상도 증분 엔코더입니다. 내구성과 정밀성이 요구되는 산업용 모션 제어 시스템을 위해 제작되었습니다.
20002568mmAutomationConnectorControlDriverEncoderIncrementalIndustrialIP64LineMILMotionOutputPPRRS422SensorshaftSolidTekelTK
방대한 재고
글로벌 배송
전문 지원
품질 보장
TEKEL TK 256 INCREMENTAL ENCODER
The TEKEL TK 256 is a high-precision incremental encoder engineered for accurate motion sensing in industrial automation systems. It delivers 2000 PPR resolution and features a durable solid shaft design with RS422 line driver output, making it ideal for demanding environments requiring reliability and precision.
Manufacturer: TEKEL
Type: Incremental Encoder
Model: TK 256
SN: G02.01348.0205
REF NO: E231749 / E252694
Code: TK2560.F.2000.24/5.S.K4.8==.LDX406
| Flange Type | Square Shaft |
| Shaft Type | Solid Shaft |
| Shaft Diameter | 8 mm |
| Resolution | 2000 PPR |
| Voltage Supply | 24 V DC |
| Output Circuits | Line Driver (5V Output) |
| Line Driver | RS422 a 5 V (26LS31) only with 5 V supply |
| Connection Type | Radial MIL Connector (7 Pins) |
| Protection Class | IP64 |
| Temperature Range | -10 to 70 °C |
