Turck BI6R-W30-DAN6X-H1141 Inductive Sensor
Manufacture: Turck
Type: Inductive Sensor
Model: BI6RW30DAN6XH1141
ID. No.: 14037
Features:
– Rectangular, height 30 mm
– Pulse duration 100 ms
– Sensitivity adjusted via potentiometer
– Dynamic output behaviour
Operating voltage: 10 … 30 V DC
DC rated operational current: ≤ 200 mA
Output function: 3-wire, NO contact, NPN
Switching frequency: 0.008 kHz
Design: Ring sensor, W30
Housing material: Plastic, PA12-GF30
Electrical connection: Connector, M12 × 1
Coil body: plastic, POM
Ambient temperature: -25 … +70 °C
Protection class: IP67
Dimensions: 60 x 35 x 30 mm
