Manufacturer: Weigel
Type: Active Normalized Signal Separator Archive
Model: TUA 2.0 L
Housing Design: housing with latch for mounting on a 35 mm mounting rail
Connection Terminals: screw terminals
Input:
Input Quantity: direct current or direct voltage
Current: 20 mA
Voltage: 10 V
Output:
Current: 4 … 20 mA
Voltage: 2 … 10 V
Output Current Limitation: to a value of max. 30 mA (on request)
Auxiliary Power Supply: 115 V ~ (85 … 126 V), 48 … 62 Hz, 24 V = (18 … 36 V)
Operating Temperature Range: 0 … + 55 ° C
Dimensions: 22.5 X 80 X 115 mm
Degree of Protection: IP 40 housing, IP 20 terminals
Weight: 0.12 Kg
