INA 3800-2RS Angular Contact Ball Bearing
Nieuw
Op voorraad1 eenheidKlaar voor verzending
Angular Contact Ball Bearing Schaeffler INA 3800-2RS angular contact ball bearing with a 10 mm bore, 19 mm outer diameter, 7 mm width, double-sided contact seals, and reinforced polyamide cage for industrial applications.
Enorme Voorraad
Wereldwijde verzending
Deskundige Ondersteuning
Kwaliteit Gegarandeerd
| Bore diameter d | 10 mm |
| Outer diameter D | 19 mm |
| Width B | 7 mm |
| Dynamic Load Capacity C | 2,080 N |
| Static Load Capacity C0 | 1,370 N |
| Fatigue load limit, radial | 72 N |
| Limiting speed | 21,100 1/min |
| Design variant | B Bearing without filling slot |
| Sealing | 2RS Contact seal on both sides |
| Cage | TVH Solid cage made of glass-fiber reinforced polyamide PA66 |
| Stock key | CON003 |
| Condition | New |
| SKU | 1101648 |
| Weight | 0,01 |
