Schneider Electric GV2P10 6.3A Motor Circuit Breaker
Motorbeveiligingsschakelaar SCHNEIDER ELECTRIC GV2P10 uit de TeSys Deca serie, 3-polig ontwerp met instelbare thermische beveiliging en hoge kortsluitvastheid voor industriële motorbeveiliging.
SCHNEIDER ELECTRIC GV2P10 Motor Circuit Breaker
The SCHNEIDER ELECTRIC GV2P10 motor circuit breaker from the TeSys Deca range is designed for reliable motor protection in industrial applications. It provides thermal and magnetic protection against overloads and short circuits, ensuring safe and efficient motor operation.
Manufacturer: SCHNEIDER ELECTRIC
Type: Motor Circuit Breaker
Model: GV2P10
Series: GV2
Range: TeSys Deca
Short Name: GV2P
Device Application: Motor Protection
| Operating Voltage | 690 V AC |
| Operational Current | 6.3 A |
| Frequency | 50 / 60 Hz |
| Thermal Protection Adjustment Range | 4 / 6.3 A |
| Magnetic Tripping Current | 91 A |
| Power Dissipation | 2.5 W |
| Rated Impulse Voltage (Uimp) | 6 kV |
| Poles | 3 |
| Motor Power 400/415 V AC | 2.2 kW |
| Motor Power 500 V AC | 3 kW |
| Motor Power 690 V AC | 4 kW |
| Rated Ultimate Short-Circuit Breaking Capacity (Icu) 230/240 V AC | 100 kA |
| Rated Ultimate Short-Circuit Breaking Capacity (Icu) 400/415 V AC | 100 kA |
| Rated Ultimate Short-Circuit Breaking Capacity (Icu) 440 V AC | 100 kA |
| Rated Ultimate Short-Circuit Breaking Capacity (Icu) 500 V AC | 100 kA |
| Rated Ultimate Short-Circuit Breaking Capacity (Icu) 690 V AC | 6 kA |
| Control Type | Rotary Handle |
| Protection Class | IP20 |
| Operation Temperature | -20 / 60 °C |
| Dimensions | 89 x 45 x 97 mm |
