Contactor SCHNEIDER TeSys Giga LC1G330KUEN industrial contactor designed for motor control and power switching applications with high operational current capacity and reliable industrial performance.

Fabrikant
SCHNEIDER
SKU
1099314
Staat
Nieuw
Delen
Enorme Voorraad
Wereldwijde verzending
Deskundige Ondersteuning
Kwaliteit Gegarandeerd
SN3606481921970
RangeTeSys
Range of ProductTeSys Giga
Product or Component TypeContactor
Device short nameLC1G
Contactor applicationPower switching,Motor control
Poles description3P
[Ue] rated operational voltage1000 V AC 50/60 Hz , 460 V DC
[Ie] rated operational current330 A (at <140 °F (60 °C)) at <= 440 V AC-3
[Uc] control circuit voltage100...250 V AC 50/60 Hz,100...250 V DC
[Uimp] rated impulse withstand voltage8 kV
Overvoltage categoryIII
[Ith] conventional free air thermal current440 A (at 104 °F (40 °C))
Rated breaking capacity2940 A at 440 V
Auxiliary contact composition1 NO + 1 NC
Product CertificationsCB Scheme, CCC, cULus,EAC,CE,UKCA,EU-RO-MR by DNV-GL
Tightening torque309.8 lbf.in (35 N.m)
Height8.9 in (225 mm)
Width5.5 in (140 mm)
Depth8.9 in (226 mm)
Ambient air temperature for operation-13…140 °F (-25…60 °C)
Attached withNNZ37820/NNZ37816 assembly kit
Stock KeyCON003
ConditionNew
SKU1099314
Weight7,5
