Siemens 1FT5106-0SF71-1-Z Brushless Servomotor
Nieuw
Beschikbaar op aanvraag
5 250,00$
BRUSHLESS SERVO MOTOR
Siemens 1FT5106-0SF71-1-Z is a powerful brushless servo motor with 360V input, 58 Nm rated torque, and integrated EBD-4B brake. Includes Siemens 2CW6144-8 blower for optimal cooling and performance.1FT5106-0SF71-1-Z2CW6144-8360V58AutomationB5blowerBrakeBrushlessDriveEBD-4BHighIndustrialIP54motormountNmServoSiemensTorqueWith
Enorme Voorraad
Wereldwijde verzending
Deskundige Ondersteuning
Kwaliteit Gegarandeerd
SIEMENS 1FT5106-0SF71-1-Z BRUSHLESS SERVO MOTOR WITH BLOWER
The Siemens 1FT5106-0SF71-1-Z is a high-performance brushless servo motor built for precision control in industrial automation. Engineered for durability and speed, it comes equipped with a Siemens 2CW6144-8 blower for enhanced thermal management and consistent performance.
Manufacturer: Siemens
Type: Brushless Servo Motors
Model: 1FT5106-0SF71-1-Z
Part No.: R825 6009 01 001
REF NO: G45+G51+K31+K64
Standard: EN 60034
| Series | 5 |
| Frame Size | 10 |
| Length | 6 |
| Rated Voltage | 360 V |
| Rated Torque | 58 Nm |
| Static Torque | 57/70 Nm |
| Stall Current | 54.0/66.0 A |
| Rated Speed | 3000 rpm |
| Max. Speed | 4500 rpm |
| Constant Voltage | 13.3 mVmin |
| Tacho Generator Type | 1FU1050-6MF |
| Brake Voltage | 24 VDC |
| Brake Power | 31 W |
| Brake Model | EBD-4B |
| Mounting Position [IM] | B5 |
| Protection Class | IP54/IP64 |
| Thermal Class | F |
| Blower Information Manufacturer | Siemens |
| Rated Voltage | 220“380 / 440 V |
| Rated Current | 0.3“0.17 / 0.18 A |
| Max. Voltage | 22“290 / 380“500 V |
| Max. Current | 0.68 / 0.39 A |
