Siemens 6EP1 436-3BA10 Power Supply Module
Nieuw
Op voorraad2 eenhedenKlaar voor verzending
Supply Module Three-phase Siemens SITOP PSU200M supply module with 400-500 V AC input and 24 V DC, 20 A output, designed for industrial automation and control applications.
Gebruikt
Op voorraad
Dit product is ook gebruikt verkrijgbaar
Bekijk gebruikte versie →
Enorme Voorraad
Wereldwijde verzending
Deskundige Ondersteuning
Kwaliteit Gegarandeerd
| Serial NO. | YSU/K7AAC2AT9 |
| Family | SITOP PSU200M |
| Type Of the Power Supply Network | 3-phase AC |
| Input Supply Voltage at 3AC | 400-500 V |
| Supply Voltage | 400-500 V |
| Output Supply | 24 V DC |
| Output Current | 20A |
| Buffering Time for Rated Value of The Output Current in the Event of Power Failure Minimum | 25 ms |
| Operating Condition of the Mains Buffering | at Vin = 120/230 V, typ. 150 ms at Vin = 400 V |
| Line Frequency | 50/60 Hz |
| Input Current | ( at rated input voltage 400 V 1.2 A), ( at rated input voltage 500 V 1 A) |
| Current Limitation of Inrush Current At 25 °C Maximum | 18 A |
| Output voltage at DC rated value | 24 V |
| Dimensions | 70 × 125 × 125 mm |
| Ambient Temperature | -25 ... 70 C |
| Condition | New |
| Stock key | CON003 |
| SKU | 1093768 |
| Weight | 1,24 |
