Siemens 7MF0310-1DL01-5SF2-Z Pressure Transmitter
Pressure Transmitter
The SIEMENS SITRANS P320 7MF0310-1DL01-5SF2-Z is a high accuracy pressure transmitter with 4 to 20 mA plus HART output, IP66 protection, 0 to 25 mbar measuring range, and ATEX explosion protection for industrial process applications.SIEMENS 7MF0310-1DL01-5SF2-Z SITRANS P320 Pressure Transmitter
The SIEMENS SITRANS P320 7MF0310-1DL01-5SF2-Z Pressure Transmitter provides high accuracy, long-term stability, and digital communication via HART protocol. Designed for precise low-pressure measurement, it ensures reliable performance in demanding industrial environments.
Manufacturer: SIEMENS
Type: Pressure Transmitter
Model: 7MF0310-1DL01-5SF2-Z
Series: SITRANS P320
Configuration Code: C14 + C11 + C20 + E20 + Y21 + Y15 + Y01
Serial Number: N1N82310126643
Order Number: 0002024299-000030 / 000017814488
Codes: 4518329598 / A7G2267245 / N1N72710092165
Firmware Version: 1.01.00
Hardware Version: 1.00.00
| Power Supply | 10.5 to 45 V DC (non IS) |
| Output Signal | 4 to 20 mA plus HART |
| Measurement Range (Y01) | 0 to 25 mbar |
| Tag Number (Y15) | WI-3351-PIT-14326 |
| Unit (Y21) | UNIT |
| Communication Protocol | HART |
| Type of Protection | IP66 |
| Housing Material | Aluminium, coated |
| Connection Type | 1/4 inch or 1/2 inch NPT or process flanges (stainless steel) |
| Process Connection Material | 1.4404 (AISI 316L Stainless Steel) |
| Diaphragm Material | 1.4404 (AISI 316L Stainless Steel) |
| O Ring Material | FPM (Viton or FKM) |
| Filling Fluid | Silicone Oil |
| Minimum Measuring Span | 1 mbar |
| Maximum Measuring Span | 60 mbar |
| Maximum Working Pressure | 160 bar or 240 bar |
| Accuracy | less than or equal to 0.065 percent of calibrated span |
| Temperature Limits | minus 40 to plus 80 degree Celsius |
| Explosion Protection | ATEX |
