Alpha SP 100Y-MF1-10-0G1-2S Planetary Gearbox

Manufacturer: Alpha

Type: Planetary Gearbox

Model: SP100Y-MF1-10-0G1-2S

Ratio: 10

Size: 100

Stages: 1-Stage

Max. Torque[Nm]: 376

Nominal Torque[Nm]: 282

Permitted Average Input Speed[rpm]: 2800

Max. Input Speed[rpm]: 5500

Max. Axial Force[N]: 5650

Max. Lateral Force[N]: 6600

Ambient Temperature[C°]: -15…40

Efficiency at Full Load: 97 %

Protection class[IP]: 65

Shaft [mm]: 32

Hollow Shaft [mm]: 24

Flange Diameter [mm]: 120

Lubrication: Opti gear Synthetic 800/220
