Anly AH5N Multi-Range Analogue Timer
Used
Available on request
Multi-Range Analogue Timer
The Anly AH5N Multi-Range Analogue Timer operates on 24 to 240 V AC with a 0-1s time range and a 250V 5A contact rating. Compact and precise, it is ideal for industrial control applications.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
Anly AH5N Multi-Range Analogue Timer
The Anly AH5N Multi-Range Analogue Timer is a reliable and precise timing device designed for industrial control applications. With a wide operating voltage range of 24 to 240 V AC and a compact design, it offers versatility and ease of integration into various automation systems.
Manufacturer: Anly
Type: Multi-Range Analogue Timer
Model: AH5N
Designed for industrial automation and control systems, the Anly AH5N provides efficient and accurate timing operations, ensuring optimal performance in demanding environments.
| Operating Voltage | 24 to 240 V AC |
| Contact Rating | 250 VAC, 5 A |
| Consumed Power | 2 VA |
| Frequency | 50/60 Hz |
| Time Range | 0 to 1s |
| Reset Time | Max 0.2s |
| Ambient Temperature | -10 to 50°C |
| Dimensions | 45 X 84 X 103 mm |
