Balluff BOS 18M-PS-1XB-E5-C-S 4 Optoelectronic Sensor
The Balluff BOS 18M-PS-1XB-E5-C-S 4 offers a 200 mm sensing range, PNP output, and IP67 protection, making it perfect for diffuse sensing applications in industrial automation and material handling systems.
Balluff BOS 18M-PS-1XB-E5-C-S 4 Optoelectronic Sensor
The Balluff BOS 18M-PS-1XB-E5-C-S 4 Optoelectronic Sensor is a high-performance sensor designed for diffuse optical sensing applications. With a rated operating distance of 200 mm and an infrared light source, this sensor ensures reliable detection in various industrial setups. It operates with a supply voltage range of 10-30V DC and features a PNP output with a switching frequency of 100 Hz. The sensor is built with a durable nickel-plated brass housing, ensuring longevity and resistance against harsh environments. Its M12 connector (S4) offers easy integration into industrial systems, while the IP67 degree of protection ensures reliable operation even in challenging environments. This sensor is ideal for use in automation, packaging, and material handling systems.
- Manufacturer: Balluff
- Type: Optoelectronic Sensor
- Model: BOS 18M-PS-1XB-E5-C-S 4
- Part No.: 126943
Technical Specifications:
- Sensor Type: Diffuse
- Supply Voltage: 10-30V DC
- Rated Insulation Voltage: 250V AC
- Rated Operational Current (Ie): 200 mA
- Switching Function: Normally Open
- Output: PNP
- Output Resistance: 33 kOhm
- Switching Frequency: 100 Hz
- Rated Operating Distance (Sn): 200 mm
- Light Source: Infrared
- Housing Material: Nickel-plated brass
- Connection: M12 Connector S4
- Degree of Protection: IP67
- Ambient Temperature: -5 to 55 °C
- Dimensions: M18 x 1 x 69 mm
The Balluff BOS 18M-PS-1XB-E5-C-S 4 Optoelectronic Sensor is ideal for use in precise detection tasks, offering exceptional performance and protection in demanding industrial environments.
