BBC VDE 0160 Relay Module
Used
In stock1 unitReady to ship
99,99$
BBC Relay Module VDE 0160
Reliable switching with supply voltage range 200-250V AC, 4A/220V contact rating, and 6A thermal current for industrial applications.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
BBC Relay Module VDE 0160
The BBC Relay Module VDE 0160 is designed for reliable switching and control of electrical systems. With a supply voltage range of 200 to 250V AC, it operates at frequencies between 40 to 60Hz. This relay module features contact ratings for both AC11 (4A at 220V and 2A at 380V), making it suitable for a wide range of applications. It has a maximum supply voltage of 300V and offers a thermal current rating of 6A. With a make current of 20 Amps and a break current of 3 Amps, it ensures safe and efficient operation in demanding conditions.
| Supply Voltage | 200...250V AC |
| Frequency | 40...60Hz |
| Contact Rating (AC11) | 4A/220V, 2A/380V |
| Maximum Supply Voltage (U supply) | 300V |
| Thermal Current | 6A |
| Make Current | 20 Amps |
| Break Current | 3 Amps |
