Beckhoff AX2020 S62000-520 Digital Servo Amplifier

Manufacturer: BECKHOFF

Type: Digital Servo Amplifier # Servo Drive

Model: AX2020

MRN: S62000-520

Rated supply voltage: 3 x 230 V / 480V

Frequency: 50 Hz

Output current: 20A rated, 40 A peak

Over voltage protection threshold:450…900 V

Auxiliary power supply:24 V

Power signals connection: Power Combicon 7.62 / 4×4 + 1×6-pole, 4mm²

Resolver input: SubD 9pole (socket)

Operating temp.: 0…45 °C

Protection: IP 20

Dimensions: 325 x 120 x 265 mm

Weight: 7.5 Kg

Condition: New
