Cannon SSI-Gateway Communication Module
Communication Module
Cannon Automata SSI-GATEWAY communication module for integrating SSI absolute encoders into Sercos III networks, featuring DIN-rail mounting, 24 VDC supply, and advanced SSI configuration options.Cannon Automata SSI-GATEWAY Communication Module
The Cannon Automata SSI-GATEWAY is a communication module designed as a standard interface for absolute encoders. It enables simple and cost-effective integration of SSI encoders from any vendor into a Sercos III network, ensuring reliable industrial communication and data exchange.
Manufacturer: Cannon-Automata
Type: Communication Module
Model: SSI-GATEWAY
Article No.: 70069300 (14)
Serial No.: 413437
PA No.: 150976
Firmware: FW 02.01.004
Code: CKS 0xA1D0
Sercos Features:
¢ Sercos FSP-Encoder, Probe & Compare
¢ 4 Real-Time Data Connections
¢ 2 Rotary Switches For Sercos Device Address
SSI Configuration:
¢ Binary Or Gray-Code
¢ None / Odd / Even Parity
¢ DataValid-Bit ON / OFF
¢ Up To 8 Data Sets For Different Encoders
Encoder Supply:
¢ 24 VDC / 120 mA
¢ 5 VDC / 330 mA
| Communication System | SERCOS |
| Housing | Plastic |
| Mounting | DIN-Rail Mounting |
| Operating Temperature | 0°C To +55°C |
| Protection Class | IP20 |
| Certifications | CE |
| ¢ Transfer Rates | 67.5 kHz “ 2 MHz |
| ¢ Encoder Resolution | 8 “ 31 Bits |
| Onboard I/Os | 2 x DI, 2 x DO |
| Supply Voltage | 24 VDC |
| Power Consumption | 300 mA |
