Dold BO5988.47/424 Emergency Stop Module
Used
In stock3 unitsReady to ship
Emergency Stop Module The DOLD SAFEMASTER BO 5988.47/424 emergency stop module features DC 24 V + AC 230 V supply voltage, 3–30 second time delay, and 4 NO + 1 NC contacts. Designed for industrial machine safety and emergency stop control applications.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
| series | SAFEMASTER |
| Art-N | 0044730 |
| Supply Voltage | DC 24V + AC 230V |
| Time Delay | 3 – 30 Sec |
| contact | 4 NO + 1 NC |
| Ambient temperature | - 15 … + 50 °C |
| EMC | IEC/EN 62 061 |
| Interference suppression | Limit value class B EN 55 011 |
| Degree of protection Housing | IP 40 IEC/EN 60 529 |
| Terminals | IP 20 IEC/EN 60 529 |
| Housing | Thermoplastic with V0 behaviour according to UL subject 94 |
| Vibration resistance | Amplitude 0.35 mm IEC/EN 60 068-2-6 frequency 10 ... 55 Hz |
| Climate resistance | 15 / 050 / 04 IEC/EN 60 068-1 |
| Terminal designation | EN 50 005 |
| Wire fixing | Plus-minus terminal screws M 3.5 box terminal with wire protection |
| Mounting | DIN rail IEC/EN 60 715 |
| Width x height x depth | 100 x 74 x 121 mm |
| Stock key | JO-004 |
| Condition | Used |
| SKU | 1101386 |
| Weight | 0,75 |
