Duplomatic 2 E4P4-S2-DI/40 Directional Control Valve

Manufacturer: DUPLOMATIC

Type: Directional Control Valve

Model: 2 E4P4-S2-DI/40

Nominal Size: 6

Type of Actuation: Electrically

Ambient Temperature Range: –20 …. +50 ^oC

Maximum Operating Pressure at Ports (P, A, B) :320 bar

Maximum Operating Pressure Port (T) :210 bar

Maximum Flow Rate: 150 l/min

Fluid Temperature Range: –20 …. +80 ^oC

Connection: Sup-Plate

Weight: 1.80 kg
