Effeff 1905 F31 Electric Door Opener
Used
In stock3 unitsReady to ship
Electric Door Opener
The EFFEFF / ASSA ABLOY 24 V GS EE Electric Door Opener is a reliable solution for efficient door operation. With a break-in resistance of 3000 N, low power consumption, and a zinc die-cast housing, it™s built for performance in AC and DC applications.24vAbloyAssaAttachment.brassdcdie-castDINDoorElectrichigh-performancelowMechanismOpenerPowerUniversalZinc
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
EFFEFF / ASSA ABLOY 24 V GS EE Electric Door Opener
The EFFEFF / ASSA ABLOY 24 V GS EE Electric Door Opener is a high-performance and durable door opening solution, designed for efficient operation in both AC and DC applications. Featuring a universal DIN-direction and a zinc die-cast housing, it ensures reliable performance with high break-in resistance and low power consumption.
Manufacturer: EFFEFF / ASSA ABLOY
Type: Electric Door Opener
Model: 24 V GS EE
Art No: 1905f31
EAN No: 4042203079403
Technical Data:
- DIN-Direction: Universal, 24 V DC eE
- Rated Operating Voltage Tolerance Range: ± 2 V
- Rated Resistance: 235 Ohm
- Current Consumption: 70 mA
- Current Consumption DC (50% Residual Ripple): 100 mA
- DC-Power Consumption (Stabilised): 105 mA
- Height: 90 mm
- Break-in Resistance: 3000 N
- Width: 16.5 mm
- Depth: 28 mm
- Operating Temperature Range: -15 °C to +40 °C
- Material Housing: Zinc Die-Cast
- Material Screw-On Attachment: Brass
- Max. Latch Preload AC: 80 N
- Max. Keeper Pre-Load DC (50% Residual Ripple): 20 N
- Max. Latch Preload DC (Stabilised): 10 N
