Eltorque QT250 Electric Valve Actuator

Manufacturer: ELTORQUE
Type: Electric Valve Actuator
Model: QT250
Motor ID: 78383

Min-max torque: 50 – 250 Nm
Min-max closing time: 13 – 60 sec
Valve spindle adapter: 17 x 17mm
Valve flange: F05, F07, F10
Input voltage: 110 … 240 VDC
Valve applications: Butterfly or ball valves with the quarter-turn operation
Dimensions H/W/D: 229/156/210 mm
Enclosure protection: IP68
Operating conditions: -25 to +55°C
Port size: 1/8″ , 6.5 mm , 5.5 mm
