F 9009 ER / SN74HC259N Integrated Chip

Type: Integrated Chip
Model: SN74HC259N
Part No.: F 9009 ER

Features:
• Wide operating voltage range of 2 V to 6 V
• High-current inverting outputs drive up to 10 LSTTL loads
• Low power consumption, 80-μA max ICC
• Typical tpd = 14 ns
• ±4-mA output drive at 5 V
• Low input current of 1 μA max
• 8-bit parallel-out storage register performs serialto-parallel conversion with storage
• Asynchronous parallel clear
• Active-high decoder
• Enable input simplifies expansion
• Expandable for n-bit applications
• Four distinct functional modes
No. of pins: 16
Operating temperature: -40 … 85°C
Package Type: PDIP
