FAG 1201 TV Self-Aligning Ball Bearing
New
In stock2 unitsReady to ship
Self-Aligning Ball Bearing
FAG 1201 TV Self-Aligning Ball Bearing features a 12 mm bore diameter and 32 mm outer diameter. Designed for high-speed applications with a limiting speed of 28,000 1/min and a glass-fiber reinforced polyamide PA66 cage.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
FAG Self-Aligning Ball Bearing 1201 TV
The FAG 1201 TV Self-Aligning Ball Bearing is designed for smooth, efficient rotation with the ability to accommodate shaft misalignment. It is ideal for applications that require high speed and load handling capabilities.
Manufacturer: FAG
Model: 1201 TV
Type: Self-Aligning Ball Bearing
| Bore Diameter (d) | 12 mm |
| Outer Diameter (D) | 32 mm |
| Width (B) | 10 mm |
| Dynamic Load Rating (Cr) | 5,700 N |
| Static Load Rating (C0r) | 1,270 N |
| Fatigue Load Limit | 80 N |
| Limiting Speed | 28,000 1/min |
| Reference Speed | 21,300 1/min |
| Cage | TV, solid cage made of glass-fiber reinforced polyamide PA66 |
