FAG 1211-K-TVH-C3 Self-Aligning Ball Bearing

Manufacturer: Schaeffler FAG

Type: Self-Aligning Ball Bearing with tapered bore

Model: 1211-K-TVH-C3

Replaces: 1211K.TV.C3



Dimensions

Bore Diameter d: 55 mm

Outer diameter D: 100 mm

Width B: 21 mm

Basic load ratings:

Dynamic C_r: 27000 N

Static C_0r: 10000 N

Fatigue load rating: 630 N

Limiting speed: 7700 rpm

Reference Speed: 6900 rpm

Cage: TVH ,solid cage made of glass-fiber reinforced polyamide PA66

Bore type: Tapered, taper 1:12

Radial internal clearance: Group 3 (C3)
