FAG 1211TV Self-Aligning Ball Bearing
In stock9 unitsReady to ship
Self-Aligning Ball Bearing
The FAG 1211TV ball bearing features a 55 mm bore diameter, 100 mm outer diameter, and a reinforced polyamide cage, offering superior performance in applications requiring misalignment compensation.1001211TV55BallbearingboreCageCompensationdiameterdurableFagHigh-SpeedIndustrialMisalignmentmmOuterPolyamideSelf-Aligning
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
FAG 1211TV Self-Aligning Ball Bearing
The FAG 1211TV Self-Aligning Ball Bearing is designed to accommodate misalignment and shaft deflections, ensuring smooth and efficient operation. Its glass-fiber reinforced polyamide cage enhances durability and performance in various industrial applications.
Manufacturer: FAG
Type: SELF-ALIGNING BALL BEARING
Model: 1211TV
| Bore Diameter (d) | 55 mm |
| Outer Diameter (D) | 100 mm |
| Width (B) | 21 mm |
| Dynamic Load Rating (Cr) | 27000 N |
| Static Load Rating (C0r) | 10000 N |
| Fatigue Load Rating | 630 N |
| Limiting Speed | 7700 rpm |
| Reference Speed | 6900 rpm |
| Cage | TV, solid cage made of glass-fiber reinforced polyamide PA66 |
