FAG 1310TV Self-Aligning Ball Bearing
New
In stock2 unitsReady to ship
Self-Aligning Ball Bearing
The FAG 1310TV is a self-aligning ball bearing with 50 mm bore, TV-type reinforced cage, and high-speed capability. Ideal for applications with shaft deflection or misalignment.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
FAG 1310TV Self-Aligning Ball Bearing
The FAG 1310TV Self-Aligning Ball Bearing is designed to accommodate misalignment and shaft deflection while maintaining smooth operation and extended service life. Equipped with a TV-type solid cage made of glass-fiber reinforced polyamide PA66, it offers lightweight strength and resistance in demanding conditions.
Manufacturer: FAG
Type: Self-Aligning Ball Bearing
Model: 1310TV
| Bore Diameter (d) | 50 mm |
| Outer Diameter (D) | 110 mm |
| Width (B) | 27 mm |
| Dynamic Load Rating | 42,000 N |
| Static Load Rating | 14,200 N |
| Fatigue Load Limit | 900 N |
| Limiting Speed | 6,900 1/min |
| Reference Speed | 6,300 1/min |
| Cage Type | TV, solid cage made of glass-fiber reinforced polyamide PA66 |
