FAG 1312TV Self-Aligning Ball Bearing
In stock1 unitReady to ship
Self-Aligning Ball Bearing
The FAG 1312TV is a self-aligning ball bearing with a 60 mm bore and 130 mm outer diameter, designed for high-speed applications and misalignment tolerance. It features a durable TV polyamide cage reinforced with glass fiber.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
FAG 1312TV Self-Aligning Ball Bearing
The FAG 1312TV Self-Aligning Ball Bearing is designed to accommodate misalignment and shaft deflection, making it ideal for applications with challenging alignment conditions. Featuring a TV solid cage made of glass-fiber reinforced polyamide PA66, this bearing offers durability, quiet operation, and high-speed performance.
Manufacturer: FAG
Type: Self-Aligning Ball Bearing
Model: 1312TV
| Bore Diameter (d) | 60 mm |
| Outer Diameter (D) | 130 mm |
| Width | 31 mm |
| Dynamic Load Rating | 58,000 N |
| Static Load Rating | 20,800 N |
| Fatigue Load Limit | 1,320 N |
| Limiting Speed | 5,500 1/min |
| Reference Speed | 5,200 1/min |
| Cage Type | TV “ Solid cage made of glass-fiber reinforced polyamide PA66 |
