FAG 2305 TV Self-Aligning Ball Bearing
New
In stock1 unitReady to ship
Self-Aligning Ball Bearing
The FAG 2305 TV is a robust self-aligning bearing with a 25 mm bore and 62 mm outer diameter. Equipped with a TV polyamide cage, it handles misalignment and high speeds up to 12,200 RPM.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
FAG 2305 TV Self-Aligning Ball Bearing
The FAG 2305 TV is a precision-engineered self-aligning ball bearing designed to compensate for shaft misalignment and reduce stress in rotating machinery. Featuring a glass-fiber reinforced polyamide PA66 cage (TV type), it offers smooth operation and excellent resistance to wear and heat.
Manufacturer: FAG
Type: Self-Aligning Ball Bearing
Model: 2305 TV
| Bore Diameter (d) | 25 mm |
| Outer Diameter (D) | 62 mm |
| Width (B) | 24 mm |
| Dynamic Load Rating (Cr) | 25,000 N |
| Static Load Rating (C0r) | 6,600 N |
| Fatigue Load Rating | 420 N |
| Limiting Speed | 12,200 1/min |
| Reference Speed | 11,900 1/min |
| Cage | TV, solid cage made of glass-fiber reinforced polyamide PA66 |
