FAG 2308K.TV.C3 Self-Aligning Ball Bearing
New
In stock8 unitsReady to ship
Self-Aligning Ball Bearing
The FAG 2308K.TV.C3 is a durable self-aligning bearing with tapered bore (K 1:12), 40 mm bore diameter, and a C3 clearance. Designed to accommodate shaft misalignment and high dynamic loads.2308K.TV.C340mmBallbearingbearingsboreC3CageClearanceFagIndustrialMisalignmentPA66Self-Aligningtapered
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
FAG 2308K.TV.C3 Self-Aligning Ball Bearing
The FAG 2308K.TV.C3 is a high-performance self-aligning ball bearing designed for applications with misalignment and shaft deflections. It features a K-type tapered bore (1:12 taper) and C3 internal clearance, making it ideal for dynamic loads in demanding industrial environments. Equipped with a TV solid cage made of glass-fiber reinforced PA66, it ensures smooth operation and durability.
Manufacturer: FAG
Type: Self-Aligning Ball Bearing
Model: 2308K.TV.C3
| Bore Diameter (d) | 40 mm |
| Outer Diameter (D) | 90 mm |
| Width (B) | 33 mm |
| Dynamic Load Rating (Cr) | 46,000 N |
| Static Load Rating (C0r) | 13,500 N |
| Fatigue Load Limit | 860 N |
| Limiting Speed | 7,900 1/min |
| Reference Speed | 8,700 1/min |
| Cage | TV, solid cage made of glass-fiber reinforced polyamide PA66 |
| Clearance | C3 |
| Bore Type | K, tapered bore (1:12) |
