FAG 3205-BD-TVH-L285 Double ROW Angular Contact Ball Bearing
Manufacturer: Schaeffler FAG
Type: Double Row Angular Contact Ball Bearing
Model: 3205BD-TVH-L285
Replaces: 3205-BD-XL-TVH-L285, 3205-B-TVH
Dimensions
Bore Diameter d: 25 mm
Outer diameter D: 52 mm
Width B: 20.6 mm
Contact angle: 30 °
Basic load ratings, radial:
Dynamic Cr: 22000 N
Static C0r: 15200 N
Fatigue load limit Cur: 1050 N
Limiting speed: 10700 rpm
Reference speed: 12500 rpm
Cage: TVH, solid cage made of glass-fiber reinforced polyamid PA66
Lubricant: L285, Grease
