FAG 3804-B-2RSR-TVH-HLC Angular Contact Ball Bearing
New
In stock2 unitsReady to ship
Angular Contact Ball Bearing
FAG angular contact ball bearing with double rubber seals, reinforced polyamide cage, and high load capacity for industrial applications.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
FAG / Schaeffler 3804-B-2RSR-TVH-HLC Angular Contact Ball Bearing
The FAG 3804-B-2RSR-TVH-HLC is a precision angular contact ball bearing designed to support combined radial and axial loads with high reliability. Manufactured by Schaeffler, this bearing features double-sided sealing and a reinforced polyamide cage for stable performance in industrial applications.
Manufacturer: FAG / Schaeffler
Type: Angular Contact Ball Bearing
Model: 3804-B-2RSR-TVH-HLC
| Bore Diameter (d) | 20 mm |
| Outside Diameter (D) | 32 mm |
| Width (B) | 10 mm |
| Basic Dynamic Load Rating, Radial (Cr) | 5,600 N |
| Basic Static Load Rating, Radial (C0r) | 4,750 N |
| Fatigue Load Limit, Radial (Cur) | 270 N |
| Limiting Speed | 10,600 1/min |
| Sealing | 2RSR “ Rubber seals on both sides |
| Cage | TVH “ Solid cage made of glass-fiber reinforced polyamide PA66 |
| Logistical Code | HLC |
