FAG 4206B.TVH Double ROW Deep Groove Ball Bearing
New
In stock1 unitReady to ship
DOUBLE ROW BALL BEARING
FAG 4206B.TVH double row deep groove ball bearing with PA66 cage, designed for high radial loads and speeds up to 9600 rpm in precision mechanical systems.304206B.TVH629600BallbearingboreCageDeepdiameterDoubleFagGrooveHigh-SpeedIndustrialmmOuterPA66Rowrpm
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
FAG 4206B.TVH DOUBLE ROW DEEP GROOVE BALL BEARING
The FAG 4206B.TVH is a precision-engineered double row deep groove ball bearing built for high radial load capacity and long service life. Featuring a glass-fiber reinforced PA66 cage and high-speed capabilities, this bearing is suitable for demanding industrial and mechanical applications.
Manufacturer: FAG
Type: Double Row Deep Groove Ball Bearing
Model: 4206B.TVH
| Bore Diameter (d) | 30 mm |
| Outer Diameter (D) | 62 mm |
| Width (B) | 20 mm |
| Chamfer Dimension (r min) | 1 mm |
| Dynamic Load Rating (Cr) | 29000 N |
| Static Load Rating (C0r) | 21600 N |
| Fatigue Load Limit (Cur) | 1130 N |
| Reference Speed | 9600 rpm |
| Limiting Speed | 9400 rpm |
| Cage Type | TVH, solid cage made of glass-fiber reinforced polyamide PA66 |
| Items per Set | 5 |
