FAG 51132MP Axial Deep Groove Ball Bearing

Manufacturer: Schaeffler FAG

Type:  Axial Deep Groove Ball Bearing single direction

Model: 51132-MP

Dimensions:

Inner diameter shaft washer d: 160 mm

Outer diameter housing washer D: 200 mm

Height T: 31 mm

Dynamic load rating, axial: 112000 N

Static load rating, axial: 425000 N

Fatigue load limit, axial: 14600 N

Limiting speed: 2550 RPM

Reference speed: 2060 RPM

Operating temperature: -30 … +150 °C

Cage material: Solid brass cage
