FAG 51220 Axial Deep Groove Ball Bearing

Manufacturer: Schaeffler FAG

Type:  Axial Deep Groove Ball Bearing single direction

Model: 51220

Dimensions:

Inner diameter shaft washer d: 100 mm

Outer diameter housing washer D: 150 mm

Height T: 38 mm

Dynamic load rating, axial: 119000 N

Static load rating, axial: 325000 N

Fatigue load limit, axial: 13300 N

Limiting speed: 2700 RPM

Reference speed: 3600 RPM

Operating temperature: -30 … +150 °C

Cage material: Steel
