FAG 53224 Axial Deep Groove Ball Bearing

In stock1 unitReady to ship

AXIAL DEEP GROOVE BALL BEARING

FAG 53224 Axial Deep Groove Ball Bearing with 120 mm inner diameter, steel sheet metal cage, and high load ratings for demanding axial load applications.

Manufacturer
FAG
SKU
1086446
Condition
New
Share
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed

FAG 53224 AXIAL DEEP GROOVE BALL BEARING

The FAG 53224 Axial Deep Groove Ball Bearing is engineered for high-load axial applications, offering exceptional precision, durability, and performance. Designed with a steel sheet metal cage and high load ratings, it ensures reliable operation even under demanding conditions.

Manufacturer: FAG

Type: Axial Deep Groove Ball Bearing

Model: 53224

Inner Diameter Shaft Washer (d)120 mm
Outer Diameter Housing Washer (D)170 mm
Height (T)40.8 mm
Outer Diameter Shaft Washer (d1)170 mm
Minimum Chamfer Dimension (rmin)1.1 mm
Dynamic Load Rating (Ca)128,000 N
Static Load Rating (C0a)385,000 N
Fatigue Load Rating (Cua)14,600 N
Limiting Speed2,550 1/min
Reference Speed3,000 1/min
CageSteel Sheet Metal
Operating Temperature-30 to +150 °C
FAG Z-572462.03.SKL Angular Contact Ball Bearing
Used

FAG

FAG Z-572462.03.SKL Angular Contact Ball Bearing

SKU: 1101669

Qty: 1

Available through quotation
FAG 22309K Spherical Roller Bearing
New

FAG

FAG 22309K Spherical Roller Bearing

SKU: 1101642

Qty: 1

Available through quotation
FAG 62206 2RS Deep Groove Ball Bearing
New

FAG

FAG 62206 2RS Deep Groove Ball Bearing

SKU: 1098526

Qty: 1

Available through quotation
FAG 529891C Ball Bearing
New

FAG

FAG 529891C Ball Bearing

SKU: 1101659

Qty: 1

Available through quotation
FAG 574976 Deep Groove Ball Bearing
Used

FAG

FAG 574976 Deep Groove Ball Bearing

SKU: 1101665

Qty: 1

Available through quotation

Related Products

FAG 51107 Axial Deep Groove Ball Bearing
Used

FAG

FAG 51107 Axial Deep Groove Ball Bearing

SKU: 1006375

Qty: 2

Available through quotation
‎51132 Thrust Ball Bearing‎
NewAvailable on request

‎51132 Thrust Ball Bearing‎

SKU: 974435

Available on request

Available through quotation
SNR 51112 Thrust Ball Bearing
New

SNR 51112 Thrust Ball Bearing

SKU: 1000463

Qty: 2

Available through quotation
SKF 51100 Thrust Ball Bearing
New

SKF 51100 Thrust Ball Bearing

SKU: 1006359

Qty: 5

Available through quotation
NSK 51110 Thrust Ball Bearing
New

NSK 51110 Thrust Ball Bearing

SKU: 1000455

Qty: 4

Available through quotation
Platinum International
Surplus, New & Used - Always Reliable
FAG SKU: 1086446
FAG 53224 Axial Deep Groove Ball Bearing
FAG 53224 Axial Deep Groove Ball Bearing
PriceOn Request
Stock1 In stock
ManufacturerFAG
CategoryThrust (Axial) Bearings
ConditionNew
SKU1086446

AXIAL DEEP GROOVE BALL BEARING

FAG 53224 Axial Deep Groove Ball Bearing with 120 mm inner diameter, steel sheet metal cage, and high load ratings for demanding axial load applications.

Description
Inner Diameter Shaft Washer (d)120 mm
Outer Diameter Housing Washer (D)170 mm
Height (T)40.8 mm
Outer Diameter Shaft Washer (d1)170 mm
Minimum Chamfer Dimension (rmin)1.1 mm
Dynamic Load Rating (Ca)128,000 N
Static Load Rating (C0a)385,000 N
Fatigue Load Rating (Cua)14,600 N
Limiting Speed2,550 1/min
Reference Speed3,000 1/min
CageSteel Sheet Metal
Operating Temperature-30 to +150 °C
Technical Specifications
Weight2,5 kg
ConditionNew
ManufacturerFAG
Type of ProductAxial deep groove ball bearing
Shelf No.250831
